12291235 REDUCERGS20T103A-G1H1D

发布日期：2026-09-24

#12291235 REDUCERGS20T103A-G1H1D
#SANY Original spare parts
WhatsApp: +86 136 8539 5801
WeChat: 13685395801
Email: pretty@chinaweiman.cn
#SANY Truck Crane #Truck Crane #SANY #STC250
12291235 REDUCERGS20T103A-G1H1D
1 11399325 Shaft,gear,output 1
2 11399328 Anti-dust baffle ring 1
3 A210414000009 Ring, retainer 1
4 60064297 Bearing 1
5 11399329 Flange 1
6 B230101000449 Seal, oil, TRE 2
7 60115997 Bearing，rolling 1
8 11399330 Ring,gear,inner 1
9 10809381 Nameplate 1
10 60024972 Seal ring, O-type 1
11 11454136 arresterGS8T89.1 1
12 A210434000007 Washer 1
13 24003146 Plug,screw 1
14 A210204000341 Screw 12
15 12291275 spline sleeveGS20T103-2A 1
16 A210204000167 Screw 4
17 A210341000002 Plug, screw 2
18 A210434000009 Washer 2

19 A210206000004 Screw 1
20 11399331 Planet carrier 1
21 60058816 Bearing 4
22 11399334 Gear,planet 4
23 A210414000029 Ring, retainer 4
24 11399332 Plate,retainer 1
25 A210414000009 Ring, retainer 1
26 11399333 Wheel 1
27 11399547 Planet carrier 1
28 60064295 Bearing 3
29 11399336 Gear,planet 3
30 A210414000006 Ring, retainer 3
31 A210414000065 Ring, retainer 1
32 11399335 Wheel 1
33 11665419 Planet carrier 1
34 60064296 Bearing 3
35 11665431 Gear,planet 3
36 A210414000104 Ring, retainer 3
37 A210414000102 Ring, retainer 1
38 11665547 Wheel 1

39 11399341 Brake seatGS8T89.1-1 1
40 A210777000046 Plug, plastic, male thread 1
41 11352810 Backup plate 1
42 11352811 Plate,friction,inner 4
43 11352812 Friction Plate,Outer 3
44 11352813 Adjusting cushion 1
45 12291272 CAPGS20T103.1-2A 1
46 A210206000004 Screw 1
47 24003393 Plug, breathing, steel ball type 1
48 11352814 PISTONGW13D38-11 1
49 A820209010113 Spring, large 12
50 A820209010114 Spring, small 12
51 60061368 Ring,retainer,flat 2
52 60061453 Ring,seal,star-shaped 1
53 60061369 Ring,retainer,flat 2
54 B230101001818 Ring, sealing, star-shaped 1
55 A31C214500355 O-ring 1
56 A210204000355 Screw 12
57 24000548 O-ring 1
