SANY Original spare parts
#SANY Original spare parts
#Sany SCP160G Counterbalance Forklift
13253702 Engine and transmission assembly
WhatsApp: 136 8539 5801
WeChat: 136 8539 5801
1 60155516 Transmission 1
2 13441527 Hydraulic Pipe Support 1
3 13418043 Oil Dipstick Extension Tube 1
4 B210780000244 Split Flange 6
5 A229900002040 Pipe Clamp 2
6 13418044 Steel Pipe Support 1
7 60241791 Engine 1 4-60
8 A210111000053 Bolt 2
9 A210204000462 Screw 4
42 61032403 Hose Assembly 1
43 10514233 Filler Cap 1
44 60046127 Hose Assembly 1
45 60028713 Pipe Clamp 2
46 14042591 Rubber pad 1
47 13830216 Pressure sensor connector 2
48 B230103004935 Rubber hose 1
10 11723966 Right gearbox support 1
11 14237678 Torque converter oil pipe bracket (2) 1
12 13687596 Bracket I 1
13 11723974 Left gearbox support 1
14 A210111000062 Bolt 6
15 A210401000006 Spring washer 6
16 A210405000008 Washer 8
SANY Original spare parts
#SANY Original spare parts
#Sany SCP160G Counterbalance Forklift
13253702 Engine and transmission assembly
WhatsApp: 136 8539 5801
WeChat: 136 8539 5801
17 13248102 Left Engine Mount 1
18 A210111000243 Bolt 6
19 A210401000004 Spring Washer 8
20 A210405000003 Washer 8
21 13418045 Steel Pipe Mount II 1
22 13248088 Right Engine Mount 1
23 B210780000838 Right Angle Connector 1
24 13424326 Engine Emergency Stop Switch Mounting Plate 1
25 13428971 Engine Connector Mounting Base 1
26 13573406 Oil Dipstick Kit 1
27 11741612 Oil Dipstick Holder 1
28 A210111000293 Bolts 3
29 A210609000118 O-Rings 1
30 10853932 Large Washers 6
31 A229900005421 Vibration Damping Pads 6
32 10854290 Spacers 6
33 A210204000362 Screws 4
34 A210110000225 Bolts 6
35 A210401000002 Spring Washers 10
36 A210405000001 Washers 10
37 A210307000001 Nuts 10
38 10038455 No. 2 Adjusting Shims 8
39 13011402 Pads 6
40 24001353 Straight Connectors 1
41 A210204000355 Screws 12
42 61032403 Hose Assemblies 1
49 60165342 Pipe Clamps 1
50 21051021 Tee Combination Connectors 1
55 14038690 Sensor Plates 2
