13253700 Radiator Assembly

发布日期：2026-02-18

SANY Original spare parts

#SANY Original spare parts

#Sany SCP160G Counterbalance Forklift

13253700 Radiator Assembly

WhatsApp: 136 8539 5801

WeChat: 136 8539 5801

1 B210780000052 Straight-through connector 2

2 13252650 Inlet pipe 1

3 13418041 Gasket 4

4 A210855000052 T-clamp 8

5 60248409 Radiator 1 4-84

6 14149594 Outlet pipe 2 1

7 A229900006067 T-clamp 1

8 60248410 Fan 1

9 13252668 Baffle 1

10 A210111000089 Bolt 3

8 60248410 Fan 1

9 13252668 Baffle 1

10 A210111000089 Bolt 3

11 13253686 Rubber Pad 2

12 A229900002031 T-Clamp 5

13 13256341 Rubber Sheet 1

14 13256335 Mounting Plate 1

15 13256327 Bracket 2

16 13448364 Expansion Tank Bracket One 1

17 A210111000018 Bolt 8

18 A210405000011 Washer 20

19 A210307000017 Nut 8

20 13448365 Expansion Tank Bracket Two 1

21 13252656 Water outlet pipe 1 1

22 14149593 Intercooled air outlet steel pipe 1

8 60248410 Fan 1

19 A210307000017 Nut 8

23 A229900002965 Hose Clamp 2

24 13287696 Water Pipe Support 1

25 11952056 Vent 2 Pipes 1

26 13815675 Water Supply Pipe 1

27 11723656 Vent 1 Pipe 1

28 11308842 Rubber Hose 1

29 13740921 Intercooler Inlet Steel Pipe 1

30 A210111000029 Bolt 4

31 60193074 Fastening Clamp SKN-67.2 1

32 13637005 Pipe Cap 1

33 A229900001347 Hose clamps 5

34 13740223 Connecting hoses 3

35 13839818 Rubber connecting pipes 1
