13253701 Exhaust Assembly

发布日期：2026-02-19

SANY Original spare parts

#SANY Original spare parts

#Sany SCP160G Counterbalance Forklift

13253701 Exhaust Assembly

WhatsApp: 136 8539 5801

WeChat: 136 8539 5801

1 13766948 Exhaust pipe No. 3 1

2 12698291 Bend insulation cotton 3

3 13742638 Insulation cotton 3 2

5 13247685 Exhaust pipe bracket 1

6 A820101331555 Exhaust pipe clamp I 1

2 12698291 Bent pipe insulation 3

7 13742636 Insulation cotton 2 1

8 12751831 Straight pipe insulation 2

9 A210111000197 Bolt 4

10 A210401000001 Spring washer 4

11 A210405000011 Washer 16

12 13247684 Muffler bracket 1

13 13433485 Muffler insulation board 1

14 13840299 Clamp support (1) 2

15 13829903 Support seat clamp 4

16 A229900000056 Shock absorber 6

17 A210111000125 Bolt 8

18 A210307000017 Nut 2

19 14149435 Exhaust tailpipe assembly 1

20 13740192 Clamp support (2) 4

21 14149433 No. 4 exhaust pipe 1

22 A210204000172 Screw 16

23 A210405000006 Washer 16

24 14149432 No. 2 exhaust pipe 1

4 13742635 Thermal insulation cotton 1 2

25 14149431 No. 1 exhaust pipe 1

26 14149428 Tailpipe heat shield 1

27 14149427 Muffler thermal insulation cotton 1
