13744477 Power Control System

发布日期：2026-02-19

SANY Original spare parts

#SANY Original spare parts

#Sany SCP160G Counterbalance Forklift

WhatsApp: 136 8539 5801

WeChat: 136 8539 5801

13744477 Power Control System

1 B210780000636 Right Angle Combination Fitting 2

2 13744277 Main Valve Assembly Drawing 1 14-12

3 B230103000475 Rubber Hose 1

4 B220401000316 Shuttle Valve 1

5 60228056 Square Flange Right Angle Fitting 1

6 B210780000174 End Straight Fitting 2

7 B210780000172 Tee Combination Fitting 1

8 B230103001395 Rubber Hose 1

9 B210780000028 Right Angle Combination Fitting 1

10 B230103002498 Rubber Hose 1

11 60110684 Open Plunger Pump 1

12 B210780000030 Right-angle combination joint 2

13 60024155 Split flange 4

14 B230103004102 Rubber hose 1

15 60015207 Rubber hose 1

16 B210780001310 Right-angle combination joint 2

17 A210307000036 Nut 4

18 A210405000011 Washer 4

19 B210780000741 Split flange 4

20 A210204000202 Screw 4

21 A210404000003 Washer 4

22 13139336 Hose Assembly 1

23 60340278 Hose 1

24 A210204000355 Screws 4

25 14259459 Suction Pipe Support Plate 1

26 B210780000004 Split Flange 6

27 A210204000462 Screws 28

28 A820203002556 Flange 1

29 B210780000141 End Straight Connector 1

30 14261214 Suction Pipe Support Steel Pipe 1

31 60110683 Composite Pump Set 1

32 60134197 Hose Assembly 1

33 B230103008189 Hose 1

34 B230103006930 Hose 1

35 B230103006271 Hose Assembly 1

36 B210780000029 Right Angle Connector 2

37 B230103005168 Hose 1

38 B230103004374 Hose 1

39 61025871 Hose Assembly 1

40 B210780001749 Pressure Test Connector 2

41 24001381 Straight-through Connector 2

42 B230103001386 Hose Assembly 1

43 B230103003966 Hose Assembly 1

44 B230103004177 Hose 1

45 13856489 Feedback Shut-off Valve Assembly 1 14-24

46 B210780000184 End Straight Connector 1

47 B230103006424 Hose 1

48 B210780000644 Split Flange 2

49 61025872 Hose Assembly 1
