13742696 Control Panel Assembly

发布日期：2026-02-20

SANY Original spare parts

#SANY Original spare parts

#Sany SCP160G Counterbalance Forklift

WhatsApp: 136 8539 5801

WhatsApp: 136 8539 5801

WeChat: 136 8539 5801

13742696 Control Panel Assembly

1 13529215 Positioning Guide Sleeve 1

2 60025888 Adjustable Steering Column Assembly 1

3 12142583 Dual Pedal 1

4 11143445 Seat Undersupport 1

5 A210405000007 Washer 19

6 A210401000017 Spring Washer 19

7 A210111000091 Bolt 7

8 12153581 Seat Mounting Plate 2

9 A210204000147 Screw 8

10 60149848 Driver's Seat 1

11 60154116 Wide Seat Armrest 1

12 SCP005884169 Connecting Stud 2

13 SCP005617930 Handlebar support bracket 1

18 10480997 Mounting sleeve 2

19 12530718 Radio speaker hole sealing plate 2

20 13420668 Connector mounting plate 1

21 13850384 Monitor bracket hole sealing plate 1

22 13854238 Cab floor wiring hole sealing plate 1

24 24003051 Stud 4

25 60099291 Electronic throttle 1

27 60207085 Proximity switch 1

28 A210405000001 Washer 6

29 A210401000002 Spring washer 6

30 A210111000037 Bolt 4

31 A210307000001 Nut 6

35 A210307000015 Nut 2

13 SCP005617930 Handle Support Base Bracket 1

14 SCP005635879 Handle Support Cover 1

15 13425467 Switch Mounting Plate One 1

16 13425478 Switch Mounting Plate Two 1

17 11775191 Handle Cable Guide Plate 1

23 14364934 Bracket 1

26 60150050 Monitor Bracket 1

32 A210405000005 Washers 6

33 A210401000015 Spring Washers 6

34 A210111000070 Bolts 10

36 A210405000006 Washers 4

37 A210401000016 Spring Washers 4

38 A210111000079 Bolts 4

39 A210307000016 Nuts 4

40 14044448 Handle Mounting Plate 1
