SANY Original spare parts

#SANY Original spare parts

#Sany SYM5310GJB6BEV2/410S18LX Pure Electric Mixer Truck Assembly

WhatsApp: 136 8539 5801

WhatsApp: 136 8539 5801

WeChat: 136 8539 5801

130101020639A Gearbox Assembly

1. Gearbox 1 (130104000347A)

2. Drive motor 1 (130101020639A002)

130104000347A Gear Reducer

1 A210111000030 Bolts 10

2 130101020639A003 Front Cover Assembly 1

3 130101020639A004 Primary Drive 1

4 130101020639A005 Secondary Drive 1

5 A210111000027 Bolts 21

6 130101020639A006 O-ring Seal 1

7 130101020639A007 Magnetic Drain Plug 1

8 130101020639A008 Combination Washer 1

9 130101020639A009 Gear Ring 1

10 130101020639A010 Tertiary Drive 1

11 130101020639A011 Locking Nut 1

12 130101020639A012 Connecting Gear 1

13 130101020639A013 Oil Dipstick 1

14 130103000273A028 Breather Plug 1

15 130101020639A014 Main Housing 1

16 130101020639A015 Main Bearing 1

17 130101020639A016 O-Ring Seal 1

18 130101020639A017 Through Cover 1

19 A210111000197 Bolt 8

20 130101020639A018 Rotary Oil Seal 1.21 130101020639A019 Output flange 1

130101020639A002 Drive motor

1. Front cover (130101020639A020)

2. Oil seal (130101020639A021)

3. Rotor assembly (130101020639A022)

4. Front bearing (130101020639A023)

5. Stator assembly (130101020639A024)

6. Rear bearing (130101020639A025)

7. Rear cover (130101020639A026)

8. Rotary transformer assembly (130101020639A027)

9. Rear flange (130101020639A028)

10. Water nozzle (130101020639A029) 2

11 130101020639A030 Junction Box Assembly 1

12 130101020639A031 Vent Valve 2

13 130101020639A032 High Voltage Cable Mounting Assembly 1

14 130101020639A033 Lifting Lug 1

15 130101020639A034 Low Voltage Cable Mounting Assembly 1
