#160102100004B155 Machine Body Assembly Group

发布日期：2026-02-28

#160102100004B155 Machine Body Assembly Group  #Sany 955K Electric Loader

#SANY Original spare parts

#SANY Original spare parts

#Sany  955K Electric Loader

WhatsApp: 136 8539 5801

WhatsApp: 136 8539 5801

WeChat: 136 8539 5801

1 160102120008A008 Washer 1

2 168899000422 main oil gallery rear plug screw 1

3 60230295 Bowl-shaped Plug 1

4 60106797 Rear Oil Seal 1

5 60326582 Plug 1

6 60272811 Safety Valve Spring 1

7 60272810 Safety Valve 1

8 60106768 Cylinder Sleeve 6

9 60272465 Hexagon Socket Head Cap Screw 22

10 60326116 Nozzle Assembly 6

11 60230317 Sealing Washer 6

12 60326514 Hollow Bolt 6

13 60230303 Hex Head Bolt 5

14 60272622 Main Oil Gallery Pressure Limiting Valve

Assembly 1

15 60326312 Self-locking Washer 22

16 60272575 Lower Thrust Plate 2

17 60272538 Upper Thrust Plate 2

18 60272459 Sealing Ring 2

19 60125032 Main Bearing Shell 7

20 60339512 Pressure And Temperature Sensor 1

21 60339511 Sealing Washer 1

22 160102100004B118 Engine Body Assembly 1 2-4

23 60272600 Cylinderical Pin 6

160102100004B118 Engine Body Assembly

1 60272898 Rivet 2

2 60272568 Bowl-shaped Plug 3

3 160102100004B120 Cylinder Body Pre-assembly 1 2-6

4 60272566 Plug, Expansion 1

160102100004B120 Cylinder Body Pre-assembly

1 60272565 Bowl-shaped Plug 4

2 60272898 Rivet 2

3 60352138 Cylinder Body 1

4 60272568 Bowl-shaped Plug 3

5 60272569 Bowl-shaped Plug 4

7 60272620 Main Bearing Bolt 4

8 60272619 Main Bearing Bolt 10

9 60326077 Cylindrical Pin With Internal Thread 3

10 168899000425 Camshaft Bushing 1

11 60272558 Bushing 6

12 60272566 Plug, Expansion 1

13 60272567 Bowl-shaped Plug 6
