#160102100004B Engine

发布日期：2026-02-28

#160102100004B Engine #Sany 955K Electric Loader

#SANY Original spare parts

#Sany 955K Electric Loader

WhatsApp: 136 8539 5801

WeChat: 136 8539 5801

160102100004B Engine (.png

1 160102100004B155 Machine Body Assembly Group 1 2-2

2 160102100004B156 Oil Seal Assembly 1 3-2

3 160102100004B157 Nozzle Group 1 4-2

4 160102100004B158 Flywheel Case Combination Group 1 5-2

7 160102100004B161 Crankshaft Sub-assembly 1 8-2

8 160102100004B162 Main Bearing Shell Group 1 9-2

9 160102100004B163 Thrust Disk Group 1 10-2

10 160102100004B164 Flywheel Combination Group 1 11-2

11 160102100004B165 Piston Connecting Rod Combination Set 1 12-2

12 160102100004B166 Cylinder Head Combination Group 1 13-2

13 160102100004B167 Cylinder Head Cover Combination Group 1 14-2

14 160102100004B168 Distribution Mechanism Combination Group 1 15-2

17 160102100004B171 Oil Pan Combination Group 1 18-2

19 160102100004B173 Engine Oil Pump Assembly Group 1 20-2

20 160102100004B039 Engine Oil Filter Assembly Group 1 21-2

23 160102100004B042 Engine Oil Filling Pipe Group 1 24-2

32 160102100004B144 Injection Pump Group 1 33-2

33 160102100004B145 Injection Pump Lubricating Oil Pipe Group 1 34-2

34 160102100004B146 Fuel Injector Group 1 35-2

35 160102100004B147 Low Pressure Oil Pipe Combination Group 1 36-2

36 160102100004B148 Fuel Filter Group 1 37-2

37 160102100004B149 High Pressure Oil Pipe Assembly 1 38-2

38 160102100004B150 Common Rail Group 1 39-2

39 160102100004B151 Air Intake Pipe Combination Group 1 40-2

43 160102100004B154 Air Filter Group 1 44-2

47 160102100004B109 Starting Motor Group 1 48-2

51 160102100004B113 Electronic Control Unit Group 1 52-2

52 160102100004B114 Electric Control System harness Group 1 53-2

53 160102100004B115 Generator Combination Group 1 54-2

54 160102100004B116 Generator Bracket Combination Group 1 55-2

160102100004B Engine-1.png

5 160102100004B159 Gear Chamber Combination Group 1 6-2

6 160102100004B160 Front End Cover Combination Group 1 7-2

15 160102100004B169 Gear Transmission Combination Group 1 16-2

16 160102100004B170 Crankshaft Belt Pulley Combination Group 1 17-2

18 160102100004B172 Oil Dipstick Combination Group 1 19-2

21 160102100004B040 Engine Oil Cooler Cover Assembly Group 1 22-2

22 160102100004B041 Engine Oil Filter Assembly Group 1 23-2

24 160102100004B043 Pressure Limit Valve Combination Set 1 25-2

25 160102100004B044 Oil-gas Separator Combination Group 1 26-2

26 160102100004B045 Water Pump Assembly Group 1 27-2

27 160102100004B046 Water Pipe Joint Assembly Group 1 28-2

28 160102100004B047 Water Outlet Pipe Combination Group 1 29-2

29 160102100004B048 Thermostat Group 1 30-2

30 160102100004B049 Fan Bracket Assembly 1 31-2

31 160102100004B050 Fan And Hub Assembly 1 32-2

40 168899004137A Supercharger Group 1 41-2

41 160102100004B152 Supercharger Lubricating Oil Pipe Group 1 42-2

42 160102100004B153 Compressor Pipeline Combination Group 1 43-2

44 160102100004B106 Exhaust Pipe Combination Group 1 45-2

45 160102100004B107 Muffler Group 1 46-2

46 160102100004B108 Tension Pulley And Belt Combination Group 1 47-2

48 160102100004B110 Packing Box Chassis Parts Combination Group 1 49-2

49 160102100004B111 Direct Shipping Part Group 1 50-2

50 160102100004B112 Parts Box Assembly 1 51-2

55 160102100004B117 Lifting Ring Group 1 56-2

56 SSW008823439 Engine Outrigger Group 1 57-2
