#10331997 Oil Cylinder, Swing, Blade #STG190C-8 Sany Motor Grader

#10331997 Oil Cylinder, Swing, Blade #STG190C-8 Sany Motor

Grader

#SANY Original spare parts

#Sany STG190C-8 Sany Motor

Grader

WhatsApp: 136 8539 5801

WeChat: 136 8539 5801

10331997 Oil Cylinder, Swing, Blade.png

1 10335365 Piston Rod 1

2 A820201001134 Cover, Pressure 1

3 A820199003185 Key, Clip, Front 1

4 A820201001135 Front cylinder cover 1

5 A820601000000 Pad, Protective 1

6 A820101000017 Cover, Protective 1

7 10330981 Cylinder Body AS 1

8 A820202004817 Piston 1

9 A820101000018 Key, Clip, Rear 1

11 A210333000011 Screw plug 2

12 A210434000009 Washer 2

13 A210414000029 Ring, Snap 1

14 B230101000193 Guide Ring 2

15 B230101000134 Seal, OK 1

16 A210609000272 O-ring 2

17 A210804000001 Fitting, Grease 2

18 A210111000088 Bolt 4

19 A820606010095 Grommet 2

20 B230101000200 Up Guide Ring 2

21 A880806030136 Seal, GS 1

22 A210609000166 O-ring 2

23 B210491000008 Retainer Ring 2

24 B230101000013 Seal 1

25 A210204000116 Screw-M5×16GB70.1 6

26 A210401000015 Washer 6

27 A880808070040 Seal, Dust 1

10331997 Oil Cylinder, Swing, Blade-1.png
