#10333258 Oil Cylinder, Lift, Blade #STG190C-8 Sany Motor Grader

#10333258 Oil Cylinder, Lift, Blade #STG190C-8 Sany Motor

Grader

#SANY Original spare parts

#Sany STG190C-8 Sany Motor

Grader

WhatsApp: 136 8539 5801

10333258 Oil Cylinder, Lift, Blade.png

1 A820201000956 Cover, Pressure 1

2 A820101990318 Gasket 3

3 12667963 Piston Rod AS 1

4 A290000000911 Bolt 2

5 A210401000006 Washer 2

6 A820201001134 Cover, Pressure 1

7 A820199003185 Key, Clip, Front 1

8 A820201001135 Front cylinder cover 1

9 A820601000000 Pad, Protective 1

10 A820101000017 Cover, Protective 1

11 10332632 Cylinder Body AS 1

12 A820202004817 Piston 1

13 A820101000018 Key, Clip, Rear 1

14 A820101000019 Spacer 1

15 A820301016385 Plug 2

16 A210414000029 Ring, Snap 1

17 B230101000193 Guide Ring 2

18 B230101000134 Seal, OK 1

19 A210609000272 O-ring 2

20 A210804000001 Fitting, Grease 3

21 A210111000088 Bolt 4

22 A820606010095 Grommet 2

23 B230101000200 Up Guide Ring 2

24 B230101000827 Seal M50×65.1×6.3 1

25 A210609000166 O-ring 2

26 B210491000008 Retainer Ring 2

27 B230101000013 Seal 1

28 A210204000116 Screw-M5×16GB70.1 6

29 A210401000015 Washer 6

30 B230101000008 Dust-Proof Ring M50X58X5X5.8 1

31 A210307000005 Nut 2

10333258 Oil Cylinder, Lift, Blade-1.png
