#60212522 Circle Drive #STG190C-8 Sany MotorGrader

发布日期：2026-03-03

#60212522 Circle Drive

#STG190C-8 Sany MotorGrader

#SANY Original spare parts

#SANY Original spare parts

#Sany  STG190C-8 Sany MotorGrader

WhatsApp: 136 8539 5801

WhatsApp: 136 8539 5801

WeChat: 136 8539 5801

3 60208230 Bearing seat 1

4 A210609000065 O-Ring-50×2.65GB3452.1 1

5 A210205000003 Screw M10×30GB71 1

6 A210651000158 Bearing 2

7 60208225 Sleeve, copper 2

8 60208226 Platen 2

9 60208218 Key 1

10 60208228 Rod, worm 1

11 60208224 Shaft 1

12 60208222 Bearing seat 1

13 A210609000165 O-ring 1

14 60208223 Sleeve,connection 1

28 A210434000008 Washer 3

29 A210333000002 Screw plug M16X1.5 3

30 A210204000014 Screw 8

31 A210401000001 Washer 20

36 60221371 Tank Body 1

1 A230101000581 Output shaft oil seal seat 1

2 60208217 Gear,worn 1

15 60208227 Wheel,driving 1

16 60208231 Retaining ring 1

17 A820606020513 PD oil seal 1

18 A210604000012 Bearing, Rolling 1

19 A210609000334 O-ring 1

20 A210604000045 Rolling bearing 1

21 A316140720011 Locking washer 1

22 60208220 Bearing cover 1

23 60208221 Cover 1

24 60208219 Adjusting shim 2

25 60208216 Cover,upper 1

26 A250299000001 Indicator, oil level 1

27 A210434000018 Washer 1

32 A210111000088 Bolt 8

33 A210401000017 Washer 8

34 A210111000090 Bolt 12

35 A210204000021 Screw 6
