#14126383 Work Implements #STG190C-8 Sany MotorGrader

发布日期：2026-03-03

#14126383 Work Implements

#STG190C-8 Sany MotorGrader

#SANY Original spare parts

#SANY Original spare parts

#Sany  STG190C-8 Sany MotorGrader

WhatsApp: 136 8539 5801

WhatsApp: 136 8539 5801

WeChat: 136 8539 5801

1 A820101322617 Plate,Seat 1

2 A820205001447 Spherical Plain Bearing Outer Ring 1

3 A820102010216 Gasket 1

4 A210401000008 Spring washer 4

5 24002241 Screw M24×50GB70.1 Grade 10.9 4

11 A210110000201 Bolt 4

15 14003916 Baffle 8

16 14003917 Baffle 8

17 11096718 Shim 6

18 12787958 Wearing Plate 4

22 A210491000144 washer 36

23 A210111000216 bolt 36

24 A210110000272 Bolt 36

25 A210491000118 High-strength steel washer 36

26 A229900005443 Bearing, Slewing 1

27 11220296 Pin Shaft 2

28 11866624 Adjusting Shim 2

29 A820103010056 Adjusting Shim 4

30 14003914 Shaft Sleeve 4

31 A210406000003 Plain washer 2

32 A210491000028 Pin 2

33 A820204000286 Slotted Nut 2

34 12101632 Bushing 2

35 14054327 Blade Support 1

36 A210491000023 Pin, Cotter 1

37 14003922 Lock Pin 1

38 A820601020160 Cover 4

39 A210111000029 Bolt 12

40 A210405000011 Washer 15

41 14077522 Cover Plate 1

42 14076110 Dust-Proof Loop Weldment 1

46 A210111000293 Bolt 2

47 A210405000007 Washer 2

48 14003919 Lock Plate 1

49 14168806 Spacer 2

50 14003921 Adjusting Shim 4

51 14003918 Pin 1

53 A210401000006 Washer 4

55 A210111000011 Bolt 3

6 A210111000200 Bolt-M24 6

7 14003923 Transitional sleeve 1

8 A210491000122 Washer 7

9 14003915 Transitional plate 1

10 14055949 Drawbar 1

11 A210110000201 Bolt 4

12 14054493 Frame Circle 1

13 A210111000203 Bolt 24

14 A210401000002 Washer 24

19 A210401000017 Washer 4

20 A210111000088 Bolt 4

21 13584884 Support, Rotary 1

43 A229900006820 Clamp, Tube, Double 7

44 B210851000002 Clamp, Tube, Single 3

45 A210804000001 Fitting, Grease 4

52 A210111000298 Bolt 1

53 A210401000006 Washer 4

54 A210108000097 Bolt 2
