13963960 Vibratory wheel assembly SSR200AC-8W3.6
1 13982342 Roller 1
4 A210491000122 Washer 24GB1230 80
23 13963927 Shock Absorber Seat Plate 2
29 13963911 Frame Connecting Support Plate 4
30 11549656 Adjusting Shim 8
36 A210333000007 Plug M48×2JB1001 2
37 A210434000020 Washer 48JB982 2
38 A210110000239 Bolt M24×100GB5782 Grade 10.9 24
39 A210307000007 Nut M24GB6170-00 Grade 10 24
40 A210111000119 Bolt M12×45 GB5783 Grade 10.9 48
41 A210491000121 Washer 12 GB1230 48
42 A210307000031 Nut 48
43 60269927 Shock Absorber YLJ-16(A) 12
44 A210204000337 Screw M12×30 GB70.1 Grade 10.9 48
2 13475983 Traveling end support 1
3 A210113000028 Bolt M24×2×60 GB5786 Grade 10.9 32
4 A210491000122 Washer 24 GB1230 80
5 A210114000053 Bolt M20×1.5×60 GB5786 Grade 10.9 48
6 A210491000132 Washer 20 GB1230 56
7 A210333000015 Plug M18×1.5 JB1001 12
8 A210453000002 Washer 18×22 JB/ZQ4454 12
9 24000543 O-ring 2
10 60075953 Rolling bearing NJ324MEQ/C5/S0GB283 4
11 10462773 Elastic retaining ring for bore 4
12 13142757 Traveling end amplitude adjustment device 1
13 13221947 Oil plate assembly 8
14 11549667 Rubber sleeve A 2
15 13207540 Splined shaft 1
16 13207343 Intermediate bearing housing 2
17 13207480 Vibrating end amplitude adjustment device 1
18 13142758 Right bearing housing 2
19 A210609000139 O-ring GB3452.1 2
20 A820299000325 Oil baffle 1
21 A210414000033 70GB894.1 retaining ring 1
22 13207909 Running support 1
23 13963927 Shock absorber base plate 2
24 A210114000016 Bolt M20×2×70 GB5786 Grade 10.9 32
25 60109047 Vent Cap 1
26 A210609000125 O-ring 1
27 A210444000001 Washer GB/T 1230 4
28 A210114000051 Bolt M14×1.5×40 GB5786 Grade 10.9 4
31 B220501000177 Piston Motor 1
32 A210509000115 Key 18×11×80 GB1096 1
33 60020195 Coupling ST A48. 60x72-Z21 64SHA 1
34 A229900006507 Magnetic Plug M16×1.5QC385 4
35 A210434000008 Washer 16JB982 4
45 10891721 Threaded Cap 8
46 10891722 Threaded Cap 8
