13489553 Air Conditioning System Assembly SSR220E.9

#13489553 Air Conditioning System Assembly SSR220E.9.png

1 60238210 Evaporator 1

2 60005664 Condenser 1

3 60005658 Compressor 1

4 A210204000221 Screw M10×30GB70.1 12.9 grade 4

5 A210401000002 Washer 12GB93 2

6 A210405000001 Washer 12GB97.1 2

7 A210111000119 Bolt M12×45GB5783 10.9 grade 2

8 13489082 Compressor bracket 1

9 A820101319357 Crescent plate 2

10 A210111000092 Bolt M8×35GB5783-00GB/T 5783 8

11 A210401000001 Washer 10GB93 10

12 A820101320930 Bend Plate 1

13 A820101348563 Adjusting Block 1

14 A210307000040 Nut M16GB6170 2

15 A210401000004 Washer 16GB93 2

16 A210405000003 Washer 16GB97.1 2

17 A210204000197 Screw 6

18 A210307000017 Nut M10GB6170 6

19 A820301014728 Hinged Bolt 1

20 60280216 Air Conditioner Accessory Box SSR220-3 1

21 A210110000304 Bolt M20×120 GB5782 Grade 10.9

22 A210401000006 Washer 20 GB93 1

23 A210307000029 Nut 1

24 A210111000079 Bolt 2

25 A210401000016 Washer 6GB93 2

26 A210405000011 Washer 10GB97.1 6

27 A210405000007 Washer 8

28 A210401000017 Washer 8GB93 8
