#13963928 Cooling Assembly

发布日期：2026-03-14

#13963928 Cooling Assembly
#SANY Original spare parts
#SANY Original spare parts
#SANY SSR220AC-8 Sany Single Drum Roller
#SANY #Roller #Road Roller #SSR220AC-8
#QualityChangestheWorld #sanyparts #Sany road roller #sany
WhatsApp: 136 8539 5801
WhatsApp: 136 8539 5801
WeChat: 136 8539 5801
13963928 Cooling Assembly

1 60271548 Radiator ZH810×385×1140-S99Y53Z44Q/SY015028 1

2 13663486 Connecting Hose SSR220E.7.1-13 1

3 A210855000052 T-type Clamp 2104329910 5

4 13526861 Intercooler Outlet Pipe 1

5 13526865 Degassing Pipe 1

6 A229900001347 Hose Clamp 2

7 13963578 Inlet Pipe Support Plate 1

8 13964163 Hoop 1

9 A210111000088 Bolt M8×16 GB5783-00 GB/T 5783 14
10 A210405000007 Washer 24
11 A210401000017 Washer 8GB93 14
12 A210307000012 Nut M8GB6170 10
13 13695616 Intercooler Intake Pipe 1
14 13695443 Turbocharger Outlet Hose 1
15 A229900002031 T-Clamp 1991783100 4
16 13529865 Side Folding Plate 2
17 A230105000064 Sealing Strip L=4500 3
18 13529866 Top Folding Plate 1
19 13526864 Engine Coolant Outlet Pipe 1
20 13695441 Intercooler intake hose 1
21 13526863 Engine coolant inlet hose 1
22 13527649 Engine intake hose 1
23 A210110000012 Bolt M12×70 GB5782 Grade 10.9 4

24 A210401000002 Washer 12 GB93 4

25 A210405000001 Washer 12 GB97.1 8

26 A820202003593 Large Washer 4

27 A210307000001 Nut M12 GB6170 4

28 A820606030583 Buffer Pad 8

29 13963552 Bushing 4

30 11236407 Rubber Pad 2

31 A229900006067 T-Clamp 3
