13967304 Gearbox Assembly
1 60244225 Pressure-resistant breather plug M16×1.5 QC410 1

2 A210204000338 Screw M12×40 GB70.1 10.9 grade 12

3 A210401000002 Washer 12 GB93 16

4 13967287 Input housing 1

5 A210507000036 Pin GB879.1 2

6 13815749 Nameplate 1

7 A210204000019 Screw M12×20 GB70.1 4

8 A210416000008 Retaining ring 150 GB893.1 1

9 A210419000014 Retaining ring 85 GB894.1 2

10 12498088 Quick Rivet 4

11 13048526 Internal Gear Ring I 1

12 A210466000003 Retaining Ring 45GB893.1 3

13 12935732 Planetary Shaft I 3

14 13048514 Planetary Gear I 3

15 12941751 Needle Roller Spacer I 3

16 60230183 Rolling Bearing P7×23.8 G2-3-5GB309 126

17 12941753 Needle Roller Baffle I 6

18 12941749 Spacer I 3

19 13186520 Planetary Carrier I 1

20 12941755 Wearing Pad I 1

21 13048511 Sun Gear I 1
22 24000579 Retaining ring 50GB894.1 2
23 13658971 Spline sleeve 1
24 60290330 Rolling bearing 6/QJ 217 M (GB294) 1
26 13625898 Input flange 1
27 60081267 Oil level gauge A15 (JB7941.2) Aluminum alloy 2
28 A210401000004 Washer 16GB93 26
29 A210204000248 Screw M16×110GB70.1 24
30 13967262 Connecting shaft 1
31 A230101000586 O-ring 2
32 B210399000005 Plug 4.33 A210609000280 O-ring 1
33 A210609000280 O-ring 1
34 12410120 Dust cover 1

35 A210310000017 Nut M18×1.5GB6173 1

36 A210434000009 Washer 18JB982 3

37 13008680 Vent bend 1

38 21030250 Pin 4

39 12940442 Sun Gear II 1

40 A210601006213 Rolling Bearing 16007GB276 1

41 12935769 Planetary Carrier II 1

42 A210416000021 Retaining Ring 55GB893.1 3

43 12941754 Needle Roller Baffle II 6

44 12935738 Planetary Shaft II 3

45 12940469 Planetary Gear II 3

46 60230184 Rolling Bearing P13×29.8G2-3-5GB309 90

47 12941752 Needle Roller Spacer II 3

48 12941750 Spacer II 3

49 A210609000020 O-ring 190×3.55 GB3452.1 1

50 12935789 Sealing ring 1

51 60165763 Rolling bearing 61940 GB276 1

52 12935783 Mounting seat 1

53 60225861 26R1 oil seal 210×240×15 Fluororubber 2

54 12935786 Output end cover 1

55 A210111000023 Bolt 8

56 A210401000001 Washer 8

57 13012642 Magnetic plug 2

58 60000443 Rolling bearing 1

59 12940364 Internal gear ring II 1

60 60219725 O-ring 425×5.3 (GB3452.1) 2

61 A210111000105 Bolt M16×20 GB5783 2

62 12940337 Flange 1

63 9181218000096 Process sealing package 1
